TLT8401 84 mm reference
84 × 1 mm
Archived component reference; choose antenna/chip and process configuration. [1]
RFID Tags · RFIDAK
Spring RFID Tire Transponders — TLT8401
TLT8401 is an embedded spring-antenna UHF transponder referenced in the archived catalog at 84 × 1 mm and 50 × 1 mm. It is a tire-manufacturing component, different from a patch applied to a finished tire.
Updated September 24, 2026
- Catalog model
- TLT8401
- Antenna construction
- Steel-wire spring with a central transponder assembly
- Catalog formats
- 84 × 1 mm or 50 × 1 mm
Technical reference
Product specifications
Model-specific data and source scope are shown together.
Archived TLT8401 reference. Current supply and tire-process qualification are not established by this catalog.
- Catalog model
- TLT8401 [1]
- Antenna construction
- Steel-wire spring with a central transponder assembly [1]
- Catalog formats
- 84 × 1 mm or 50 × 1 mm [1]
- Catalog mass / packing
- 0.2 g; 100 per bag [1]
- RF protocol
- EPC Gen2 / ISO 18000-6C [1]
- Installation stage
- Embedded during an approved tire-manufacturing process [1]
Choose a reference
Models & configurations
Choose a model or format to include it in your quote or sample request.
50 mm spring reference
50 × 1 mm
Shorter archived assembly; RF behavior must be evaluated separately. [1]
Appearance & construction
Photos & drawings
Open a picture to inspect the original file. Dimensions are taken from the cited references.
Application & selection
Before choosing this product
Vulcanization is a complete process
Temperature alone does not describe tire curing. Pressure, dwell, rubber compound, placement and repeated strain affect the assembly. A storage-temperature number is not a vulcanization qualification.
Evaluate the finished tire
Readability after embedding depends on the compound, wheel, antenna position and reader. Test the finished tire in its intended scanning geometry, including relevant wear or retread stages.
Sources & documents
Technical references
Published specifications identify the reference model. They do not replace the final order drawing or a model-specific test report.
- Archived component catalog — physical references ↗
Catalog / drawing reference · reviewed 2026-09-20
Custom orders & samples
Request your configuration
Choose the reference, then add quantity, destination, chip or reader details and any artwork on the enquiry page.
